Readytosky 1.2G/1.3G VTX/VRX 800mW video transmitter and receiver for 9 channels

Price:2 088 uah with VATPrice in USD:49.95

Bonuses will be issued for this product upon purchase

Read more

Brand: ReadytoskySKU 17189

• Приемник
• Передатчик

Select the option!

In stock:

Buy

You can buy this item with delivery in Ukraine

This item is available for order by legal entities for paying non-cash and includes VAT.

Out of stock

Notify when available

Description

The Readytosky 1.2G/1.3G VTX/VRX 800mW video transmitter and receiver is a 1.2/1.3 GHz version of the long-range FPV system from this manufacturer, which is designed to work in pairs, with 9 working channels. Control is carried out via buttons and light indication. A dipole SMA antenna is included with each module.

Specifications

Transmitter.

• Frequency range: 1060~1380MHz
• Number of channels: 9
• Output power: 0.1/25/200/800mW
• Рабочие частоты：1080/1120/1160/1200/1240/1280/1320/1360/1258 МГц
• Audio: 6.5/6.0MHz
• Modulation type: FM
• Frequency stability: ± 100kHz
• Accuracy: ± 200kHz
• Sensitivity: 26 ± 2dB
• Antenna port: 50 ohms
• Video format: NTSC/PAL
• Video input signal level: 1V ± 0.2V
• Audio input level: 1V ± 0.2V
• Operating temperature: -10℃ to +60℃
• Power supply voltage: DC 7-28V
• Output voltage: DC 7.28V; DC 5V
• Module dimensions: 45.5x35.8x8.4 mm
• Mounting scheme: 30.5x30.5 mm
• Weight: 10g

Receiver

• Operating frequency range: 1050~1380MHz
• Power supply: 5,0В
• Current consumption: (280 ± 40) mA
• Operating temperature: -10~+65 ºC
• Antenna port: 50 ohms
• Sensitivity: -95 dB ~ +5 dB
• Video signal system: PAL/NTSC.
• Audio input impedance: 1 kΩ
• Video output impedance: 75 ohms
• Video output level: 1В
• Video polarity: negative
• Video frequency response: ± 5 dB, max. 50 Hz ~ 6 MHz
• Differential gain: ±5%, max.
• Differential phase: ± 5 degrees, max.
• RSSI output voltage: 1.3~0.7В
• Audio output impedance: 2 kΩ,
• Audio output level: 1 ± 0,2 В
• Audio output frequency range: 100 Hz ~ 20 kHz
• Audio: 6.0 MHz (AR), 6.5 MHz (AL)
• Audio accuracy: ± 30 kHz
• Module size: 44x27x27 mm
• Weight: 20 g

Notes on setup and operation

Transmitter

I. Push-button control and LED indicators

1. Green indicator 4 pcs: 0.1 mW (0)/25 mW (D)/200 mW (C)/800 mW (H), default setting is 0.1 mW when the power is on.
Switching to the next power level can be cycled and the corresponding power indicator will flash each time you press and hold the button.
*Note: The transmit power must be adjusted after each power failure.

2 Frequency indicators (9pcs, red color). This operation can be repeated in a cyclical fashion, with each short press on the corresponding frequency point lighting up the indicator.
*Note: The operating system has a memory function, the system will save the current frequency point after a power failure.

II. Selecting the interface

The antenna is SMA interface; the antenna head is "male thread + hole" and the antenna rod is "female thread + pin". The "pin" configuration is a 1.2G special customized "Y" type antenna.
The connection sequence is as follows:
1. power input DC 7-28V;
2. input ground;
3. video input;
4. 6.5M audio input;
5. DC output 7-28 V;
6. DC grounding output;
7. DC output 5V.

Receiver

I. Push-button control and LED indicators. Frequency indicators (9pcs, red color) - Similar to the transmitter.

II. Interface definition and connection sequence: similar to the transmitter.

III. The reserved 5P contact pads are defined in the following order:
1. power input DC 7-28V;
2. input ground;
3. video input;
4. output DC 5V;
5. DC output ground.

Package contents

• 1 x Readytosky 1.2G/1.3G VTX/VRX video transmitter/receiver for 9 channels
• 1 x SMA dipole antenna
• 1 x contact cable
