JR Transmitter Module TBS Crossfire TX LITE

Price:6 918 uah with VATPrice in USD:165.49

Bonuses will be issued for this product upon purchase

Read more

Brand: TBSSKU 14556

Out of stock

Notify when available

Description

Team Black Sheep is renowned for its success in long distance flying, extreme mountain or challenging urban environments. During numerous tests around the world, TBS gathered a list of requirements and found that no existing system could meet them all. Thus, TBS began the long journey to build an RC communications system from the ground up to provide first-class reliability and state-of-the-art functionality.

TBS Crossfire TX LITE is a state-of-the-art transmitting JR module for radio equipment, with -130dB sensitivity and full diversity that provide quality communications over long distances up to 30-40 km.

Crossfire TX LITE is based on the latest RF technology capable of self-healing two-way communication in case of signal loss. Through the OLED display on the transmitter, you can track the real-time location of your drone (requires TBS GPS or BlackBox with DJI Naza or APM-based GPS). The uplink and downlink are displayed on the screen, as well as configuration options via the OLED display eliminating any customization tools via PC. A flickering LED indicator displays your link level in color (green = continue, orange = deploy). In case of a crash, the drone's location is also visible on the OLED. The receiver's built-in battery automatically turns it into a beacon, and it will continue to transmit its last known location until the battery runs out.

Built-in telemetry opens up new possibilities in system control, from firmware updates, to customizing the video transmitter channel, to adjusting flight control parameters such as PID coefficients. Adaptive bandwidth controls the transmission rate or optimizes it to reach the maximum range. Crossfire's proprietary CRSF protocol between receiver and transmitter provides very low latency with incredible throughput (3 times faster, 6 times more data than any comparable protocol). This tight integration makes TBS Crossfire the logical choice for those flying Betaflight, Raceflight, KiSS, ArduPilot, and Pixhawk firmware.

Despite the non-standard size of the module, thanks to the JR adapter with 3M Velcro, it can be installed in almost any radio equipment FrSky, FlySky and others.

The LITE version differs from the basic version of TBS CROSSFIRE TX only by the absence of Bluetooth.

Features

• Long range, reliable remote control system
• Immunity to on-board interference
• Two-way communication channel with real communication channels and telemetry
• Self-recovery and frequency hopping (DSSS, FHSS)
• Adaptive bandwidth management and range optimization
• Serial protocol transmission capability (uplink and downlink)
• RX beacon mode for locating a downed drone
• Super easy tethering and customization with built-in display
• Low latency, 150Hz update rate (3 times faster than conventional RC connections)
• Two receiver models: 8-channel Diversity Rx, 4-channel PPM / SBUS mini receiver (not included)
• 8 or 12 channel output via PPM / SBUS / CRSF on both receivers (receivers not included)
• Ability to fly with multiple pilots at the same time (10 or more)
• Selectable RF power from 10mW to 2W
• Special head-tracking input for full immersion in FPV
• LED on transmitter shows connection status, OLED display for configuration
• Short range telemetry output for mobile applications
• Fully customizable with OpenTX and TBS TANGO using CRSF protocol
• CRSF protocol interface for Betaflight, Kiss and Raceflight
• Expansion port to support future features
• Micro receiver fits even small quadcopters
• Software updates via RF communication

Features

• Frequency bands: 868mHz (EU, Russia) / 915mHz (USA, Asia, Australia)
• Input Voltage: 3.5 - 13V
• Power Consumption: 1.1W at 10mW / 3.2W at 2W
• Dimensions: 55 x 89 x 15mm
• Weight: 76g

Accessories

• 1 x JR module TBS Crossfire TX LITE
• 1 x TBS Crossfire JR adapter
• 1 x TBS Crossfire Stock TX V2 antenna
• 1 x Crossfire Futaba cable
• 1 x Crossfire Graupner cable
• 1 x Crossfire PWM Pigtail
• 1 x Crossfire JST - XT30 cable

Files

• Руководство пользователя TBS Crossfire TX LITE на английском языке
• Клиент TBS Agent X для обновления прошивики (MacOSX)
• Клиент TBS Agent X для обновления прошивики (Windows)
